HOSE CART · GARDEN
StarSeries II
Large capacity, plenty of comfort — for large gardens and grounds.
Art.-Nr. 11456
- 01 High hose capacity: 120 m at 1/2".
- 02 Full 3/4″ water flow-through — continuous through the entire unit. Plenty of water in little time.
- 03 Stainless comfort connection bend — for a kink-free water feed.
- 04 Ø 200 mm solid rubber wheels with steel rims — robust and smooth-running.
- 05 Reinforced star bracket, bolted at 6 points — maximum torsional rigidity.
- 06 Drum lock secures the drum during transport.
- 07 Spring steel nozzle holder — sprayer or spray lance always within reach.
- 08 Galvanically zinc-plated all-steel — corrosion protection for garden and outdoor use.
- 09 Brass rotating water connector G 3/4", ball-bearing-mounted, pressure-resistant up to 25 bar.
- 10 Ergonomic crank with 140 mm lever — force-saving and precise.
- 11 5-year functional warranty. 10 years on spare parts.
WHEELS
200 mm solid rubber with steel rim.
Ø 200 mm solid rubber wheels with steel rim — robustly built for high load capacity and sure footing, even on uneven ground.
Smooth handling, high running stability — for long distances in the garden and on the grounds.
Wheels that carry where it gets heavy.
WATER ROUTING
Comfort connection at 3/4″.
Stainless comfort connection bend with kink protection right at the water connection.
Full 3/4″ water flow-through — continuous through the entire cart, full pressure at the spray lance. Brass rotating water connector, ball-bearing-mounted, pressure-resistant up to 25 bar.
Full pressure at the spray lance.
CONSTRUCTION
Star bracket bolted at 6 points.
Bolted triangular frame with a reinforced star bracket bolted at 6 points — one step more robust than the entry model.
Maximum torsional rigidity for intensive continuous use. Load forces are channelled cleanly into the frame.
Hose goes. Cart stays.
DRUM LOCK
Locked for transport.
A secure drum lock holds the drum in place during transport.
The hose stays neatly wound, even when the cart is pulled over gravel, ramps or thresholds. Lock, pull, arrive.
Securely locked. Cleanly transported.
HOSE HOLDER
Clicked in. Done.
The stainless spring steel hose holder clamps the sprayer or spray lance securely during transport.
One press and the tool is seated — quickly out of the holder, quickly back in.
An everyday detail that saves time.
Technical data
Fits every hose.
Common diameters — depending on application and desired reach.
| Diameter | Capacity |
|---|---|
| Ø 13 mm (1/2") | 120 m |
| Ø 16 mm (5/8") | 100 m |
| Ø 19 mm (3/4") | 80 m |
Documents
Star Series II — everything to download.
Documents, instructions and technical data — as PDFs.
